The Eaton 9SX UPS offers high availability, flexibility and advanced protection for infrastructure, industrial, medical, IT, networking, storage and telecom. Delivering on-line double conversion protection in versatile Rack/Tower format with up to 95% efficiency.
Form Factor
- Rackmount/Tower
Output Operation Voltage (Min)
- 200 V
Output Operation Voltage (Max)
- 240 V
Input Operation Voltage (Min)
- 176 V
Input Operation Voltage (Max)
- 276 V
Efficiency
- 98%
Crest Factor
- 3:1
Output Power
- 4500 W
Output Connections
- 8 x IEC-320-C13 & 2 x IEC-320-C19
Nominal Output Voltage
- 200-240 V
AC Outlets Quantity
- 10 AC outlet(s)
Nominal Input Voltage
- 200-240 V
AC Outlet Types
- C13 coupler, C19 coupler
RS-232 Ports
- 1
Display Type
- LCD
Input Frequency
- 50/60 Hz
USB 2.0 Ports Quantity
- 1
Safety
- IEC/EN 62040-1, UL 1778, CSA 22.2
Ethernet LAN (RJ-45) Ports
- 0
Noise Level
- 45 dB
Certification
- IEC/EN 62040 -2, FCC Class A, IEC/EN 62040-3 CE, CB (TUV), UL
Operating temperature (T-T)
- 0 - 40 °C
Weight
- 48 kg
Depth
- 685 mm
Width
- 130 mm
Height
- 440 mm
Harmonized System (HS) code
- 85078000
Product colour
- Black
Brand
- Eaton
