ATEN VE814AT is an HDBaseT Video Transmitter that is capable of sending HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring dual synchronous outputs, the VE814AT can transmit video signal to two remote displays and one at the local side. This HDCP 2.2-compliant transmitter meets the HDMI Specification, including 3D, Deep Color, the maximum data rate of (10.2 Gbps), and 4K video quality up to 100 m.
The VE814AT supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE814AT). In addition, it supports Long Reach Mode that extends HDMI signals up to 150 m, 1080p, via a single Cat 5e/6 cable.
The VE814AT is a powerful solution for where digital signage is required, such as bars, educational spaces, and public transportation stations, allowing display of identical contents at different spots.
The VE814AT supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE814AT). In addition, it supports Long Reach Mode that extends HDMI signals up to 150 m, 1080p, via a single Cat 5e/6 cable.
The VE814AT is a powerful solution for where digital signage is required, such as bars, educational spaces, and public transportation stations, allowing display of identical contents at different spots.
HDCP Version
- 2.2
Supported Graphics Resolutions
- 1920 x 1080 (HD 1080), 4096 x 2160
Serial Interface Type
- RS-232
HDBaseT Port
- Yes
Plug and Play
- Yes
DC-In Jack
- Yes
HDCP
- Yes
Maximum Refresh Rate
- 60 Hz
Cable Types Supported
- Cat5e, Cat6, Cat6a
RJ-45 Output Ports
- 1
3D
- Yes
Number of HDMI Outputs
- 1
RJ-45 Input Ports
- 1
Remote (IR) Output
- 1
Remote (IR) Input
- 1
HDMI In
- 1
Consumer Electronics Control (CEC) Support
- Yes
Extended Display Identification Data (EDID)
- Yes
Serial Ports Quantity
- 1
Electrostatic Discharge (ESD) Protection
- 15 kV
Ethernet LAN
- No
Material
- Metal
Product colour
- Black
Quantity per pack
- 1 pc(s)
Country of origin
- Taiwan
Height
- 30 mm
Width
- 123 mm
Depth
- 140.2 mm
Weight
- 450 g
Bandwidth
- 340 MHz
Operating temperature (T-T)
- 0 - 40 °C
Operating relative humidity (H-H)
- 0 - 80%
Connectivity technology
- Wired
Maximum transfer distance
- 150 m
Storage temperature (T-T)
- -20 - 60 °C
Rack Mounting
- Yes
Maximum Resolution
- 4096 x 2160 pixels
AC Adapter Included
- Yes
Brand
- ATEN
