Button mounting on rear and sides, variable mounting bracket. 1U/2U form factor ePDUs can be mounted horizontaly, vertically, or under a surface.
PDU Types
- Metered
Form Factor
- Rackmount
Rack Capacity
- 1U
Firmware Upgradeable
- Yes
Rack Mount Kit
- Yes
AC Outlet Types
- C13 coupler
Maximum Current
- 10 A
Maximum Power
- 2300 W
Monitoring
- Current
Nominal Input Voltage
- 230 V
Supported Network Protocols
- HTTP, HTTPS, SSL, Telnet, FTP, SNMP, SMTP, DNS, DHCP, LDAP, RADIUS
Power Plug
- C14 coupler
Cable Colour
- Black
AC Outlets Quantity
- 8 AC outlet(s)
Nominal Output Voltage
- 230 V
Output Connections
- 8 x C13
Maximum Input Current Per Phase
- 10 A
Input Connection Type
- IEC-320-C20
Firmware Upgradeable Via
- Network, USB
Operating temperature (T-T)
- 0 - 60 °C
Mounting
- Horizontal
Product Colour
- Black
Height
- 203 mm
Width
- 44.5 mm
Depth
- 482.6 mm
Weight
- 2.6 kg
Cable length
- 3 m
Package weight
- 3.8 kg
Cables included
- LAN (RJ-45)
Certification
- CB, CE, EN 60950-1:2006/A11:2009/A1:2010/A12:2011 Safety - Part 1: General Requirements, IEC 60950-1(ed.2), IEC 60950-1(ed.2);am1 EN 55022:2010, EN 61000-6-2:2005 Part 6-2, EN 50581 : 2012, REACH, WEEE, PEP, ISO 9001:2008, ISO 14001:2004
Rack Mounting
- Yes
Ethernet LAN (RJ-45) Ports
- 1
Compliance Certificates
- RoHS
Management Protocols
- SNMP, Telnet
AC Input Frequency
- 50 Hz
Display
- LCD
Brand
- Eaton
