Eaton 9PX1000IRT2UBS. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 1000 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 8 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 7 Ah, Battery voltage: 12 V. Form factor: Rackmount/Tower, Product colour: Black, Silver, Display type: LCD. Compliance certificates: CE, Certification: IEC/EN 62040-1 UL 1778 IEC/EN 62040-2 cULus EAC TUV CSA 22.2 FCC 15 / B CISPR22 B
Battery Voltage
- 12 V
Display Type
- LCD
USB Port Type
- USB Type-B
Waveform
- Sine
Rack Mount Kit
- Yes
AC Outlet Types
- C13 coupler
Power Plug
- C14 coupler
AC Outlets Quantity
- 8 AC outlet(s)
Number of Batteries Supported
- 4
Serial Ports Quantity
- 1
Output Power
- 1000 W
Power Protection Features
- Overdischarge
Quick Installation Guide
- Yes
ECO Mode
- Yes
Efficiency
- 91.5%
Input Operation Voltage (Max)
- 276 V
Input Operation Voltage (Min)
- 100 V
Serial Interface
- Yes
Typical Backup Time at Full Load
- 6 min
Efficiency (ECO Mode)
- 97.5%
UPS Topology
- Double-conversion (Online)
Output Operation Voltage (Max)
- 240 V
Output Operation Voltage (Min)
- 200 V
Certification
- IEC/EN 62040-1 UL 1778 IEC/EN 62040-2 cULus EAC TUV CSA 22.2 FCC 15 / B CISPR22 B
Product Colour
- Black, Silver
Height
- 500 mm
Width
- 320 mm
Depth
- 570 mm
Weight
- 37.5 kg
USB port
- Yes
Operating temperature (T-T)
- 0 - 40 °C
Operating relative humidity (H-H)
- 0 - 96%
Cables included
- Input power cable, Serial, USB cable
Operating altitude
- 0 - 3000 m
Noise Level
- 35 dB
Compliance Certificates
- CE
USB 2.0 Ports Quantity
- 1
Sustainability Certificates
- ENERGY STAR
Battery Technology
- Sealed Lead Acid (VRLA)
Sustainability Compliance
- Yes
Battery Capacity
- 7 Ah
Input Frequency
- 40/70 Hz
Serial Interface Type
- RS-232
Form Factor
- Rackmount/Tower
Brand
- Eaton
