POWER AND THROUGHPUT\nEdge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.\nGroundbreaking AV GUI\nA simplified user interface makes it easy to assign configuration profiles to each port.\nMulticast in an Instant\nNETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.\nSleek, Quiet Design\nLess fan noise, and mounting ears included for rack mounting.\nAutomatic Configuration\nAuto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.\nFAST, EASY CONFIGURATION FOR AV PROS\nA streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.\nFOCUS ON THE EVENT NOT FAN NOISE\nMost models have quiet mode which greatly reduces fan noise.\nDESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX\nWith built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
Built-in Processor
- Yes
Power over Ethernet (PoE) Power Per Port
- 90 W
Broadcast Storm Control
- Yes
User Guide
- Yes
Rack Mount Kit
- Yes
Included Power Plug Types
- EU, NA, UK
Power Connector
- AC-in jack
Form Factor
- 1U
Power Source
- AC
Processor Model
- ARM Cortex-A57
Power Supply
- 750 W
Sustainability Compliance
- Yes
Processor Frequency
- 1800 MHz
Rate Limiting
- Yes
Non-operating Altitude
- 0 - 3000 m
AC Input Frequency
- 60 Hz
AC Input Voltage
- 100 - 240 V
Management Protocols
- SNMP V1, V2, V3
Authentication
- Guest VLAN, MAC-based authentication
BPDU Filtering/Protection
- Yes
Loop Protection
- Yes
Virtual LAN Features
- MAC address-based VLAN, Private VLAN, Voice VLAN
Spanning Tree Protocol
- Yes
Link Aggregation
- Yes
Flow Control Support
- Yes
Root Protection
- Yes
GARP VLAN Registration Protocol (GVRP)
- Yes
10G Ethernet (Copper) Ports Quantity
- 36
Installed SFP Plus Modules Quantity
- 0
Installed SFP Modules Quantity
- 0
Authentication Type
- RADIUS, TACACS+
6to4 Tunnel
- Yes
IPv4 Routes
- 512
IPv6 Routes
- 256
Access Control List (ACL) Egress
- 1023
Access Control List (ACL) Ingress
- 511
IGMP Proxy
- Yes
Static Port Security
- Yes
Policy-based Routing
- Yes
DoS Attack Prevention
- Yes
Queue Scheduling Algorithms
- Strict Priority Queue (SPQ), Weighted random early detection (WRED)
Multicast Listener Discovery (MLD) Snooping
- Y
Routing Protocols
- OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2
Airflow Direction
- Front-to-back airflow
sFlow
- Yes
SFP28 Ports Quantity
- 4
Power over Ethernet 4PPoE (PoE++) Ports Quantity
- 36
Password Protection
- Yes
MAC Address Filtering
- Yes
DHCP Features
- DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
LED indicators
- Yes
Switching capacity
- 920 Gbit/s
MAC address table
- 16000 entries
Number of VLANs
- 4093
10G support
- Yes
Basic switching RJ-45 Ethernet ports type
- 10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity
- 36
ARP inspection
- Yes
Switch layer
- L3
Switch type
- Managed
Operating altitude
- 0 - 3000 m
Storage relative humidity (H-H)
- 0 - 95%
Storage temperature (T-T)
- -20 - 70 °C
Latency (10 Gbps)
- 2.75 µs
VLAN support
- Yes
Networking standards
- IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u
Cables included
- AC, USB Type-C
Operating relative humidity (H-H)
- 0 - 90%
Operating temperature (T-T)
- 0 - 45 °C
Power consumption (typical)
- 148 W
Weight
- 7.33 kg
Depth
- 400 mm
Width
- 440 mm
Height
- 43.2 mm
Product Colour
- Black
Web-based Management
- Yes
Compliance Certificates
- BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
Store-and-forward
- Yes
Noise Level
- 54 dB
Memory Type
- DDR4-SDRAM
Stackable
- Yes
Rack Mounting
- Yes
IGMP Snooping
- Yes
Access Control List (ACL)
- Yes
Latency (1 Gbps)
- 2.54 µs
Throughput
- 684.48 Mpps
Full Duplex
- Yes
Quality of Service (QoS) Support
- Yes
Total Power over Ethernet (PoE) budget
- 1760 W
Power over Ethernet (PoE)
- Yes
Power Consumption (max)
- 454 W
Power Supply Included
- Yes
Flash memory
- 512 MB
Internal memory
- 4096 MB
Multicast support
- Yes
Packet buffer memory
- 64 MB
Jumbo frames
- 12000
Jumbo frames support
- Yes
Brand
- Netgear
