POWER AND THROUGHPUT
Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plusâ„¢ provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.
FAST, EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.
FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.
DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plusâ„¢, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plusâ„¢ provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.
FAST, EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.
FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.
DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plusâ„¢, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
Product Colour
- Black
Height
- 43.2 mm
Width
- 440 mm
Depth
- 400 mm
Weight
- 7.33 kg
Power consumption (typical)
- 148 W
Operating temperature (T-T)
- 0 - 45 °C
Operating relative humidity (H-H)
- 0 - 90%
Cables included
- AC, USB Type-C
Networking standards
- IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u
VLAN support
- Yes
LED indicators
- Yes
Storage temperature (T-T)
- -20 - 70 °C
Storage relative humidity (H-H)
- 0 - 95%
Operating altitude
- 0 - 3000 m
Switch type
- Managed
Switch layer
- L3
ARP inspection
- Yes
Basic switching RJ-45 Ethernet ports quantity
- 36
Basic switching RJ-45 Ethernet ports type
- 10G Ethernet (100/1000/10000)
10G support
- Yes
Number of VLANs
- 4093
MAC address table
- 16000 entries
Switching capacity
- 920 Gbit/s
Latency (10 Gbps)
- 2.75 µs
Jumbo frames support
- Yes
Jumbo frames
- 12000
Packet buffer memory
- 64 MB
Multicast support
- Yes
Internal memory
- 4096 MB
Flash memory
- 512 MB
Power Supply Included
- Yes
Power Consumption (max)
- 454 W
Power over Ethernet (PoE)
- Yes
Total Power over Ethernet (PoE) budget
- 1760 W
Quality of Service (QoS) Support
- Yes
Web-based Management
- Yes
Full Duplex
- Yes
Throughput
- 684.48 Mpps
Latency (1 Gbps)
- 2.54 µs
Access Control List (ACL)
- Yes
IGMP Snooping
- Yes
Rack Mounting
- Yes
Stackable
- Yes
Memory Type
- DDR4-SDRAM
Noise Level
- 54 dB
Store-and-forward
- Yes
Compliance Certificates
- BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
Policy-based Routing
- Yes
Flow Control Support
- Yes
Link Aggregation
- Yes
Spanning Tree Protocol
- Yes
Virtual LAN Features
- MAC address-based VLAN, Private VLAN, Voice VLAN
Loop Protection
- Yes
BPDU Filtering/Protection
- Yes
Authentication
- Guest VLAN, MAC-based authentication
Management Protocols
- SNMP V1, V2, V3
AC Input Voltage
- 100 - 240 V
AC Input Frequency
- 60 Hz
Non-operating Altitude
- 0 - 3000 m
Built-in Processor
- Yes
Processor Frequency
- 1800 MHz
Sustainability Compliance
- Yes
Power Supply
- 750 W
Processor Model
- ARM Cortex-A57
Power Source
- AC
Form Factor
- 1U
Power Connector
- AC-in jack
Included Power Plug Types
- EU, NA, UK
Rack Mount Kit
- Yes
User Guide
- Yes
Broadcast Storm Control
- Yes
Power over Ethernet (PoE) Power Per Port
- 90 W
Rate Limiting
- Yes
DHCP Features
- DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
MAC Address Filtering
- Yes
Password Protection
- Yes
Power over Ethernet 4PPoE (PoE++) Ports Quantity
- 36
SFP28 Ports Quantity
- 4
sFlow
- Yes
Airflow Direction
- Front-to-back airflow
Routing Protocols
- OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2
Multicast Listener Discovery (MLD) Snooping
- Y
Queue Scheduling Algorithms
- Strict Priority Queue (SPQ), Weighted random early detection (WRED)
DoS Attack Prevention
- Yes
Root Protection
- Yes
Static Port Security
- Yes
IGMP Proxy
- Yes
Access Control List (ACL) Ingress
- 511
Access Control List (ACL) Egress
- 1023
IPv6 Routes
- 256
IPv4 Routes
- 512
6to4 Tunnel
- Yes
Authentication Type
- RADIUS, TACACS+
Installed SFP Modules Quantity
- 0
Installed SFP Plus Modules Quantity
- 0
10G Ethernet (Copper) Ports Quantity
- 36
GARP VLAN Registration Protocol (GVRP)
- Yes
Installed SFP+ Modules Quantity
- 0
MPN
- XSM4340CV-100NES
Brand
- Netgear
