The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
Jumbo frames support
- Yes
MPN
- 7ZT7A00546
Chipset
- Intel® C624
Host Interface
- PCI Express
Interface
- Fiber
Other Operating Systems SUpported
- VMware vSphere ESXi
Flow Control Support
- Yes
Compliance Certificates
- RoHS
Fiber Ports Quantity
- 2
Ethernet LAN Data Rates
- 10000 Mbit/s
Quality of Service (QoS) Support
- Yes
Certification
- UL recognized to UL60950-1 2nd Edition FCC Rules, Part 15, Class A Australian EMC Framework (RCM) Japan VCCI, Class A Industry Canada, ICES-003, Class A EU (CE Mark) Korea KC-RRA, Class A
Jumbo frames
- 9728
Number of VLANs
- 4096
Internal
- Yes
Connectivity technology
- Wired
Networking standards
- IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x
Maximum data transfer rate
- 10000 Mbit/s
Server operating systems supported
- SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016
Security algorithms
- SNMP
Ethernet LAN
- Yes
Compatible products
- SR630 SR650 SR850 SR860 SR950
Harmonized System (HS) code
- 85176990
Product Colour
- Green, Metallic
Brand
- Lenovo
