The Intel X710 family of 10 Gigabit Ethernet (GbE) server network adapters addresses the demanding needs of the next-generation data center. By providing unmatched features for server and network virtualization, small packet performance, and low power; the data center network is flexible, scalable, and resilient.
The X710 is available in three host connections: a standard PCIe host interface, a Mezzanine LOM (ML2) host interface for ThinkSystem and System x servers, and an AnyFabric host interface for ThinkServer systems.
The X710 is available in three host connections: a standard PCIe host interface, a Mezzanine LOM (ML2) host interface for ThinkSystem and System x servers, and an AnyFabric host interface for ThinkServer systems.
Storage relative humidity (H-H)
- 5 - 80%
MPN
- 7ZT7A00534
Component For
- Server
Wake-on-LAN Ready
- Yes
Host Interface
- PCI Express
Interface
- Ethernet
Flow Control Support
- Yes
Ethernet LAN (RJ-45) Ports
- 2
Certification
- EN55022 EN55024 EN 61000-3-2 EN 61000-3-3 ICES-003, Issue-004 FCC 47 CFR Part 15 Class A VCCI AS/NZS CISPR 22 / C-tick RRL for KC BSMI UL 94 V-1
Jumbo frames
- 9500
Jumbo frames support
- Yes
Operating altitude
- 0 - 2134 m
Storage temperature (T-T)
- -20 - 65 °C
Internal
- Yes
Connectivity technology
- Wired
Networking standards
- IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1as, IEEE 802.1p, IEEE 802.3ae, IEEE 802.3x
Maximum data transfer rate
- 1000 Mbit/s
Operating relative humidity (H-H)
- 10 - 90%
Operating temperature (T-T)
- 0 - 55 °C
Harmonized System (HS) code
- 85176990
Quantity per pack
- 1 pc(s)
Product Colour
- Green, Silver
Brand
- Lenovo
