New ePDU G3 In-Line Metered Input models upgrade existing basic installation to include, including ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address.
PDU Types
- Metered
Form Factor
- Rackmount
Rack Capacity
- 0U
Firmware Upgradeable
- Yes
Rack Mount Kit
- Yes
AC Outlet Types
- IEC 60309
Maximum Current
- 16 A
Maximum Power
- 3700 W
Nominal Input Voltage
- 230 V
Display
- LCD
Power Plug
- IEC 60309
Cable Colour
- Black
AC Outlets Quantity
- 1 AC outlet(s)
Nominal Output Voltage
- 230 V
Output Connections
- 1 x IEC 309
Maximum Input Current Per Phase
- 16 A
Firmware Upgradeable Via
- Network, USB
Operating temperature (T-T)
- 0 - 60 °C
Mounting
- Vertical
Product Colour
- Black
Height
- 53 mm
Width
- 52 mm
Depth
- 311 mm
Weight
- 1.82 kg
Cable length
- 3 m
Package weight
- 2.82 kg
Cables included
- LAN (RJ-45)
LED indicators
- Yes
Rack Mounting
- Yes
Ethernet LAN (RJ-45) Ports
- 1
Compliance Certificates
- RoHS
Management Protocols
- SNMP, Telnet
AC Input Frequency
- 50 Hz
Brand
- Eaton
