Switch outlets & IT equipment across A and B feed + meter the input and branch circuits
ePDU G3 Switched models allow lights-out control of devices including switching devices powered across multiple ePDUs. They include IEC Class 1 (±1%) billing grade accuracy, an advanced hot-swap meter with LCD pixel display showing V, W, A and kWh, and the ability to daisy chain 8 ePDUs to share the same network connection and IP address.
ePDU G3 Switched models allow lights-out control of devices including switching devices powered across multiple ePDUs. They include IEC Class 1 (±1%) billing grade accuracy, an advanced hot-swap meter with LCD pixel display showing V, W, A and kWh, and the ability to daisy chain 8 ePDUs to share the same network connection and IP address.
Nominal Input Voltage
- 230 V
Display
- LCD
Supported Network Protocols
- HTTP, HTTPS, SSL, FTP, SMTP, DNS, DHCP, LDAP, RADIUS
Form Factor
- Rackmount
Rack Capacity
- 1U
Firmware Upgradeable
- Yes
Rack Mount Kit
- Yes
AC Outlet Types
- C13 coupler
Maximum Current
- 16 A
Maximum Power
- 3700 W
Monitoring
- Voltage
AC Input Frequency
- 50 Hz
PDU Types
- Switched
Power Plug
- C20 coupler
Cable Colour
- Black
AC Outlets Quantity
- 8 AC outlet(s)
Serial Ports Quantity
- 1
Nominal Output Voltage
- 230 V
Output Connections
- 8 x C13
Maximum Input Current Per Phase
- 16 A
Firmware Upgradeable Via
- Network, USB
Cable length
- 3 m
Mounting
- Horizontal
Product colour
- Black
Package width
- 375 mm
Package depth
- 570 mm
Package height
- 195 mm
Height
- 43 mm
Width
- 445 mm
Depth
- 203 mm
Weight
- 3.4 kg
Package weight
- 5.8 kg
Operating temperature (T-T)
- 0 - 60 °C
Cables included
- LAN (RJ-45)
LED indicators
- Yes
Certification
- CB, CE, EN 60950-1:2006/A11:2009/A1:2010/A12:2011\nEN 61000-6-2:2005\nEN 50581 : 2012, REACH, WEEE\nISO 9001:2008 / ISO 14001:2004
Rack Mounting
- Yes
Ethernet LAN (RJ-45) Ports
- 1
Compliance Certificates
- RoHS
Management Protocols
- SNMP, Telnet
Brand
- Eaton
