The EV2740S has all the features you need for a crisp, clear, and flicker-free display. With 4K UHD resolution, it displays four times as much information as standard Full HD (1920 x 1080) resolution. This means users can see more information at once on the 27-inch screen, reducing the need to scroll or switch between hidden windows. Although 4K monitors typically require more power due to their higher resolution and larger screen size, the EV2740S boasts a typical power consumption of just 12 watts. This helps companies reduce energy costs and minimize their environmental footprint. Like all EIZO 4K monitors, the EV2740S is equipped with a USB-C port. This transmits the video signal, provides access to the monitor's USB hub with four ports for peripheral devices, and delivers up to 70 watts of power—all with just one cable between the notebook and the screen. In Picture-by-Picture (PbyP) mode, the monitor displays images from two signal sources side by side. The EV2740S is certified to comprehensive global sustainability standards, including TCO Certified generation 10 and the ENERGY STAR® label. The EPEAT Gold award, the highest level, and EPEAT Climate+ underscore EIZO's commitment to sustainability.
Panel mounting interface
- 100 x 100 mm
Height adjustment
- Yes
Tilt adjustment
- Yes
Tilt angle range
- -5 - 35°
Swivelling
- Yes
Product Colour
- Black
Harmonized System (HS) code
- 85285210
Swivel angle range
- 0 - 344°
VESA mounting
- Yes
Warranty period
- 7 year(s)
Pivot angle
- -90 - 90°
Feet colour
- Black
Touchscreen
- No
Power consumption (typical)
- 12 W
Power consumption (standby)
- 0.27 W
Operating temperature (T-T)
- 5 - 35 °C
Operating relative humidity (H-H)
- 20 - 80%
Cables included
- USB Type-C to USB Type-C, AC
Storage temperature (T-T)
- -20 - 60 °C
Storage relative humidity (H-H)
- 10 - 90%
Certification
- CE, UKCA, CB, TÃœV/GS, TÃœV/Ergonomics (including ISO 9241-307), TCO Certified Generation 10, TÃœV/Low Blue Light Content, TÃœV/Flicker Free, RCM, cTÃœVus, FCC-B, CAN ICES-3 (B), TÃœV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC
Power Consumption (max)
- 149 W
Compliance Certificates
- CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), GS mark, ICES, PSE, RCM, RoHS, cTUVus, UKCA, VCCI, WEEE
AC Input Voltage
- 100 - 240 V
AC Input Frequency
- 50/60 Hz
Quick Start Guide
- Yes
Sustainability Certificates
- ENERGY STAR, EPEAT Climate +, EPEAT Gold, TCO
Cable Lock Slot
- Yes
Display Diagonal
- 68.6 cm (27")
Display Diagonal (metric)
- 68.5 cm
Display Resolution
- 3840 x 2160 pixels
Sustainability Compliance
- Yes
Pivot
- Yes
Native Aspect Ratio
- 16:9
HDM Ports Quantity
- 1
Cable Lock Slot Type
- Kensington
HD Type
- 4K Ultra HD
Supported Graphics Resolutions
- 720 x 400, 1280 x 1024 (SXGA), 3840 x 2160, 800 x 600 (SVGA), 2560 x 1440, 1600 x 1200 (UXGA), 1024 x 768 (XGA), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Built-In Speaker(s)
- Yes
Number of Speakers
- 2
RMS Rated Power
- 2 W
Response Time
- 6 ms
Market Positioning
- Office
Display Technology
- LCD
Contrast Ratio (Typical)
- 1000:1
Colour Gamut Standard
- sRGB
Panel Type
- IPS
Built-in USB Hub
- Yes
USB Hub Version
- 3.2 Gen 1 (3.1 Gen 1)
HDCP
- Yes
Maximum Refresh Rate
- 60 Hz
HDMI
- Yes
HDCP Version
- 1.4/2.3
DisplayPorts Quantity
- 1
Colour Depth
- 10 bit
AMD FreeSync
- No
Backlight Type
- W-LED
Depth (With Stand)
- 230 mm
Depth (Without Stand)
- 60.7 mm
Digital Horizontal Frequency
- 31 - 134 kHz
Display Brightness (Typical)
- 350 cd/m²
Energy Consumption (SDR) Per 1000 Hours
- 13 kWh
Energy Efficiency Class (SDR)
- C
Energy Efficiency Scale
- A to G
Flicker-Free Technology
- Yes
Headphone Out
- No
Height (With Stand)
- 376.3 mm
Height (Without Stand)
- 364.3 mm
Low Blue Light Technology
- Yes
Number of USB Type-C Upstream Ports Quantity
- 1
NVIDIA G-SYNC
- No
On Screen Display (OSD) Languages
- German, English, Spanish, French, Italian, Swedish
On Screen Display (OSD)
- Yes
Pixel Density
- 163 ppi
Pixel Pitch
- 0.155 x 0.155 mm
Screen Shape
- Flat
Stand Included
- Yes
USB Power Delivery Up To
- 70 W
USB Type-A Downstream Ports Quantity
- 4
USB Type-C DisplayPort Alternate Mode
- Yes
Viewable Size, Horizontal
- 59.7 cm
Viewable Size, Vertical
- 33.6 cm
Weight (With Stand)
- 8.6 kg
Width (With Stand)
- 611.6 mm
Width (Without Stand)
- 611.6 mm
Display Number of Colours
- 16.7 million colours
Number of Upstream Ports
- 1
USB Upstream Port Type
- USB Type-C
Viewing Angle, Horizontal
- 178°
Viewing Angle, Vertical
- 178°
Weight (Without Stand)
- 5.8 kg
Digital Vertical Frequency
- 29 - 61 Hz
Anti-Glare Screen
- Yes
Built-in Camera
- No
LED Backlight
- Yes
Picture-by-Picture (PbP)
- Yes
USB Power Delivery (USB PD)
- Yes
MPN
- EV2740S-BK
Automatic Brightness Control
- Yes
Look-up table (LUT) bit depth
- 10
Adjustable Height (max)
- 16.9 cm
Response time measurement type
- GTG (Gray to Gray)
Brand
- EIZO
